The Core Dredge 30 is a 12 inch dredger that is designed and produced for maximum return on investment for activities such as river dredging, sand mining, river training, harbour deepening, dredging of irrigation channels and much more. The Core Dredge concept is a modular one that allows to be versatile and function in different surroundings in different configurations such as plain suction, dredge wheel, cutter suction dredger on either spud poles or winches.


Production: 1500 m3/hour
Total Installed power: 300 kW
Dredge installation
Dredge pump drive: Caterpillar, Iveco, Volvo or Doosan
Power:
230kW@2200 rpm
Dredge pump: GIW/WARMAN
Cutter: ECTMarine
Teeth system: Replaceble teeth
Cutter power: 40 kW
Cutter speed: Variable 0..30 rpm
Main Dimensions
Length overall, ladder up: 18 m
Length over pontoons: 12 m
Breadth: 4,5 m
Dredging depth: 7 m
Suction pipe diameter: 350 DN
Discharge pipe diameter: 300 DN
Auxiliary drive
(Driving electric generator, winches, cutter, spuds)
Auxiliary engines: Caterpillar, Iveco, Volvo or Doosan
Power: 70kW@2200rpm
Winches
Ladder winch
Line pull first layer: 25 kN
Speed: 0..20 m/min
Swing winches (2x)
Wire pull first layer: 25 kN
Hauling speed: 0..20 m/min
Electric installation
Voltage: 24V DC/230V
Electric generator Alternator:
24 V DC
Tank capacities
Fuel oil: 6 m3
Optional equipment
Production measurement
Dredge monitoring tracking system
Increased dredging depth
Airconditioning
Plain suction front part
Spare part package
Spud carrier system
Diesel generator set
UWP (Underwater pump)
Electric powered
Features
High efficiency dredge pump
Transportable by road
High quality components
Efficient fuel consumption
Luxurious operator cabin
Modular design
Heavy duty design
