Workboat 104

ECTMarine workboats are heavy duty workboats for different applications in the marine industry. The general design is a multicat type vessel, that can work in shallow waters as well as coastal area’s. The vessels are available in different sizes and with a variety of options and in different configurations such as dredge support vessel, supply vessel, carrier, pusher/ tug.  The workboats have a spacious deck and are maneuverable to perform activities in confined area’s.

Information Leaflet WB 104

Propulsion

Propulsion engine                        Doosan

Power (approx)                             166 kW

Propellers                                       1x 4 blade fixed pitch propeller

Steering system                             Hydraulic plate rudder

Deck equipment

Anchor handeling winch

Line pull first layer                        25 kN

Towing bitt

Bow roller

Wooden work deck

Ship systems:

Compass, VHF, Fire extinguishers

Navigation and interior lights

Electric bilge pump

Mechanical ventilation

Internal cooling system

Hydraulic system powered by main engine

Grease pump and toolkit

Tank capacities

Fuel oil 4 m3

Main characteristics

The hull is a fully welded, longitudinally stiffened©

The main marine engine with reduction gearbox is located in

the engine room.

Propulsion of the workboat will be realized by a fixed pitch propeller.

Steering is with plate rudder and powered by hydraulic steering gear.

The wheelhouse is constructed of steel and has acoustic and thermal insulation.

Main Dimensions

Length overall                                 10 m

Beam                                                 4 m

Height                                               1,5 m

Draught                                            1 m

Electric instalation

Alternator                                        24V DC

Quantity                                           1X

Capacity                                           1X 60A

Batteries

Quantity                                           2X

Capacity                                           200 Ah

Performance

Bollard pull ahead                         2 ton

Speed (approx)                               7 knots

Deck crane (SWL)                          74 kNm

Classification (optional)

Bureau Veritas / Holland Register
Class I X HULL · MACH special service / Workboat Coastal Area

Optional Equipment

Diesel generator 230V with main switch board

Anchor mooring winch

Radar system

GPS
