ECTMarine workboats are heavy duty workboats for different applications in the marine industry. The general design is a multicat type vessel, that can work in shallow waters as well as coastal area’s. The vessels are available in different sizes and with a variety of options and in different configurations such as dredge support vessel, supply vessel, carrier, pusher/ tug. The workboats have a spacious deck and are maneuverable to perform activities in confined area’s.
Propulsion engine Doosan, Volvo, Caterpillar
Power (approx) 230kW
Propellers 1x 4 blade fixed pitch propeller
Steering system hydraulic plate rudder
Anchor handeling winch
Line pull first layer 30 kN
Wooden work deck
Compass, VHF, Fire extinguishers
Navigation and interior lights
Electric bilge pump
Internal cooling system
Hydraulic system powered by main engine
Grease pump and toolkit
Fuel oil 5 m3
The hull is a fully welded, longitudinally stiffened©
The main marine engine with reduction gearbox is located in
the engine room.
Propulsion of the workboat will be realized by a fixed pitch propeller.
Steering is with plate rudder and powered by hydraulic steering gear.
The wheelhouse is constructed of steel and has acoustic and thermal insulation.
Length overall 12 m
Beam 5 m
Height 1,5 m
Draught 1 m
Alternator 24V DC
Capacity 1X 60A
Capacity 200 Ah
Bollard pull ahead 3 ton
Speed (approx) 6,5 knots
Deck crane (SWL) 9,6 tm
Bureau Veritas / Holland Register
Class I X HULL · MACH special service / Workboat Coastal Area
Diesel generator 230V with main switch board
Anchor mooring winch
